Double head printer/ direct to garment

DMP-16120TX Printers

DMP-16120TXOptimize Your Production

Instant pause and cancel function while printing

optimized printer in production. while printing, instant pause and cancel transaction at printer itself

Auto height control system

pile of products can be printed using auto forwarding mode without separate command

Aluminum fabric jig

durable and convenient to use using aluminum material

Auto ink refill monitoring system

program which computer is monitoring the ink volume virtually while printing can refill the ink automatically if needed to minimize the printing defect

Digital control system

through digitalized programming in replacement of analog sensor control, printing position will be more accurate without movement of sensor

Division Specifcation
Print head Piezoelectric inkjet
Max. Print size 1600mm x 1200mm (63in x 47.3in)
Max. resolution maximum 1440dpi
Print speed 258 sqft/hr (24m2/hr)(5pass)/215 sqft/hr (20m2/hr)(6pass)
Head Clearance 130mm (5.1in)
Proudct size (W)2750mm x(L) 800mm x (H)1295mm /177kg(108in x 31in x H:50in/390lb)
Input power AC 100 to 120V ±10%, 8.2A, 50/60 Hz or AC 220 to 240V ±10%, 4.2A, 50/60 Hz
Operation system Window XP / vista/Window7/Window8
Application software topaz rip
